Mk Acoustic
Model : XD 4.11
Thương hiệu : U.S.A
Xuất xứ : China
Model Name | XD 4.11 |
GS1 (EAN) CODE | 4.26032E+12 |
System Type | 4-Channel Class D Amplifier |
Output Power | 4 x 2700W @ 2Ohm |
all channels driven | 4 x 1830W @ 4Ohm |
20Hz - 20 kHz, 0.1 % THD | 4 x 1100W @ 8Ohm |
Output Power | 2 x 5000W @ 4Ohm |
Bridge mode | 2 x 3660W @ 8Ohm |
2 x 3200W @16Ohm | |
THD+N @ 8Ω 1kHz,1dB | ≤0.06% |
Slew Rate | >50v/μs |
Frequency Response | 10Hz -34kHz / ±0.3dB |
@1Watt, 8Ohm | |
Damping Factor | >3000 |
(1kHz and below) | |
Signal to Noise Ratio | >104dBA |
20Hz -20 kHz | |
Channel Separation | >75dB |
Crosstalk@1kHz | |
Voltage Gain | 41,7dB (0,775V:113V) |
Input Sensitivity | selectable 0.775V/1V/1.4V/2V |
Input Impedance | 20k Ohm Balanced |
10k Ohm Unbalanced | |
Front Control | Power switch, Gain control |
Rear Control | Sensitivity Switch, |
Mode Switch | |
LED Indicators | Signal VU Meter |
Protect, | |
Parallel, | |
Bridge | |
Input Connectors | XLR Active balanced |
pin1 gnd / pin 2+ / pin3- | |
Output Connectors | 4 Neutrik NL4 Sockets |
Cooling | Low Noise Continuously Variable |
speed fan | |
Protection | Full short circuit, Open circuit, |
thermal, Ultrasonic, RF Protection. | |
Stable Into reactive or | |
Mismatched loads | |
Load Protection | On/Off muting |
DC fault power | |
Supply shutdown | |
Operating Voltage | 230V (+/- 10%), 50-60Hz |
USA Version | |
110V (+/- 10%), 50-60Hz | |
Fuse | T-25A |
Dimensions (h/w/d) | 19“/1U 483W x 402D x 44H |
Net weight | 8,2 kg |
